| Item | Property |
|---|---|
| Model Name | E3 WAVE Aero S |
| System Type | 1-PICS(Single Phase) |
| Cooling Capacity | 15kW with 25℃ ambient air (L2A) |
| 30kW with 32℃ inlet water (L2L) | |
| IT Capacity | 6U |
| PUE | <1.2 @15kW (L2A) |
| <1.05 @30kW (L2L) | |
| Dimension | 1360 x 798 x 1190 (W x D x H, mm) |
| Option | L2A, L2L, L2R |
| Accessory | Hoist, Server Tray |
| Item | Property |
|---|---|
| Model Name | E3 WAVE Flow N |
| System Type | 1-PICS(Single Phase, L2L) |
| Cooling Capacity | 120kW @W32 |
| IT Capacity | 24U |
| PUE | 1.03 |
| Dimension | 2250 x 970 x 1550 (W x D x H, mm) |
| Item | Property |
|---|---|
| Model Name | E3 WAVE Flow S |
| System Type | 1-PICS(Single Phase) |
| Cooling Capacity | 50kW with 32℃ inlet water (L2L) |
| IT Capacity | 15U |
| PUE | <1.05 @50kW |
| Dimension | 1500 x 895 x 1300 (W x D x H, mm) |
| Item | Property |
|---|---|
| Model Name | E3 WAVE DL1P-W-1368 |
| System Type | 1 Phase, In-Row / L2L |
| Cooling Capacity | 1368kW |
| Rack Quantity | 8-10 |
| PUE | <1.2 @300kW |
| Dimension | 905 x 1235 x 2085 (W x D x H, mm) |
