냉매 없는 전기 냉각의 혁신ElectricEES-08 (POU)- Channel
- Temp. Range (℃)
- -10 ~ +80
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 8.0kW @ 20℃
- Installation Location
- Direct Type
- Weight(kg)
- 85
- Dimension(mm)
- 600(W) x 520(D) x 420(H)
-
냉매 없는 전기 냉각의 혁신ElectricEES-08 (POU)- Channel
- Temp. Range (℃)
- -10 ~ +80
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 8.0kW @ 20℃
- Installation Location
- Proximity Type
- Weight(kg)
- 95
- Dimension(mm)
- 460(W) x 460(D) x 750(H)
-
냉매 없는 전기 냉각의 혁신ElectricEES-08 (RCP)- Equipment Chamber
- Channel
- Temp. Range (℃)
- -10 ~ +80
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 8.0kW @ 20℃
- Installation Location
- Direct Type
- Weight(kg)
- 250
- Dimension(mm)
- 640(W) x 990(D) x 1,700(H)
-
냉매 없는 전기 냉각의 혁신ElectricEES-08 (RCP)- Equipment Chamber
- Channel
- Temp. Range (℃)
- -10 ~ +80
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 8.0kW @ 20℃
- Installation Location
- Proximity Type
- Weight(kg)
- 250
- Dimension(mm)
- 640(W) x 990(D) x 1,700(H)
-
중저온 공정의 안정적 파트너Combi(R＋H)RDHS-181512- Equipment Chamber
- Bottom
- Channel
- Cold Loop(Channel 1)
- Temp. Range (℃)
- -40 ~ +30
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 11kW @ -20℃
- Weight(kg)
- 690
- Dimension(mm)
- 600(W) x 1,100(D) x 1,900(H)
-
고효율 열교환의 표준Heat ExchangerHS-04- Equipment Chamber
- Channel
- Temp. Range (℃)
- 40 ~ +70
- Temp. Stability (℃)
- ±0.3
- Cooling Capacity (kW)
- 9.0kW @ 40℃
- Weight(kg)
- 160
- Dimension(mm)
- 300(W) x 700(D) x 1,500(H)
-
높은 내구성 및 안정적인 운영 신뢰성General RefrigerantRS-18- Temp. Range (℃)
- -40 ~ +40
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 7.0kW @ -20℃
- Weight(kg)
- 385
- Dimension(mm)
- 400(W) x 950(D) x 1,800(H)
-
극저온 공정의 최적 대응CryogenicRSHD-833T- Equipment Chamber
- Top
- Channel
- Channel 3
- Temp. Range (℃)
- 30 ~ +90
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 10kW @ 40℃
- Weight(kg)
- 923
- Dimension(mm)
- 600(W) x 1,100(D) x 1,900(H)
-
CO2 냉매로 친환경 전환 선도Natural RefrigerantSODA-C- Temp. Range (℃)
- -30 ~ +70
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 13 KW @ -10℃
- Refrigerant
- R-744(CO2)
- Fluid (Coolant)
- Fluorinert(FC-3283), SF-10 (or Up to customer)
- Electricity
- 208 volts, 3P3W PE, 60Hz, Breaker : 50A
- Weight(kg)
- 320
- Dimension(mm)
- 450(W) x 850(D) x 1350(H)
-
냉동기·열교환 기술을 융합한 고효율 플랫폼Combi(R＋H)RSHS-1812- Equipment Chamber
- Bottom
- Channel
- Cold Loop 1(Channel 1)
- Temp. Range (℃)
- -40 ~ +40
- Temp. Stability (℃)
- ±0.1
- Cooling Capacity (kW)
- 7.5kW @ -20℃
- Weight(kg)
- 440
- Dimension(mm)
- 450(W) x 1,000(D) x 1,800(H)
