| Item | Property |
|---|---|
| Model Name | E3 WAVE Flow A |
| System Type | 1-PICS(Single Phase, L2L) |
| Cooling Capacity | 50kW @W32 |
| IT Capacity | 24U |
| PUE | ≤1.2 |
| Dimension | Tank: 1500 × 1148 × 1804 (W × D × H mm) |
| CDU: 800 × 1150 × 1650 (W × D × H mm) |
| Item | Property |
|---|---|
| Model Name | E3 WAVE Aero S |
| System Type | 1-PICS(Single Phase, L2A) |
| Cooling Capacity | 20kW @W32 |
| IT Capacity | 6U |
| PUE | ≤1.2 |
| Dimension | 1360 x 798 x 1190 (W x D x H, mm) |
| Item | Property |
|---|---|
| Model Name | E3 WAVE Flow N |
| System Type | 1-PICS(Single Phase, L2L) |
| Cooling Capacity | 80~240kW @W32 |
| IT Capacity | ≤1.1 |
| PUE | ≤1.2 |
| Dimension | 1850 x 970 x 1500 (W x D x H, mm) |
