| Category | Property |
|---|---|
| System Type | 1-PICS (Single Phase) |
| Cooling Capacity | 50kW/W32 (Min.) |
| PUE | ≤ 1.04 |
| Rack Size | 24U |
| Server Width | Basic: 19" (21" Available) |
| Server Depth | 940mm |
| Redundancy | 2N (System, Pump) |
| Dimension | Tank: 1500 × 1148 × 1804 (W × D × H mm) |
| CDU: 800 × 1150 × 1650 (W × D × H mm) | |
| Coolant Volume | Tank: 670L, CDU: 71L (741L) |
| Weight | 1,208 kg |
| CDU Power Supply | 380~415V 3P 50/60Hz |
| Monitoring | Temperature, Pressure, Level Sensor (TBD: Diagnostics, AFP (Auto Fail Prediction) |
